Productivity
  • Auto Torque Up – Climb slopes and carry heavy loads with ease. The EP-CB’s built-in intelligence detects when additional power is needed and automatically increases torque to help ensure smooth, stress-free driving at all times.
  • Intelligent Load Indicators and Limits (Option) – A load indicator gives operators a general idea of the loads they’re carrying. The truck also intelligently reduces its travel speed according to its current load weight and lift weight. If it’s carrying too much, an overweight warning is set off
  • Maximum Travel Speed Function - Limiting maximum speed: Controls travel speed so the truck does not exceed the upper limit preset.
Productivity
Operator comfort
  • Fingertip Control (optional) – Enable operators to take precise, efficient control of their lift trucks. Fingertip control allows operators to control hydraulics with a never-seen-before level of precision that levers simply cannot match enabling them to work faster, more accurately and more safely.
  • Low Center of Gravity - A lower center of gravity coupled with the deeper emplacement of the battery box provides excellent traveling and turning stability.
  • Wide Visibility - Excellent multi-directional visibility help ensure a wide field of vision.
Operator comfort
Awareness
  • Orange seatbelt (option) - encourages accountability and proper safety implementation. The password entry option locks forklift operation behind a password. And the emergency stop button is free from any dashboard obstructions.
  • Load Indicator And Overload Warning (option) - The load indicator displays the approximate weight of goods being lifted. A visual warning will alert the operator if the load exceeds the maximum weight capacity.
  • Travel Hydraulic Interlock - This sensitive power-severance feature disengages all movement if the operator is not seated in the forklift. This intelligent feature takes forklift safety to the next level.

Awareness
Reliability
  • Better Efficiency with an AC Motor - High-quality AC motor drives these trucks, delivering smooth rides, faster acceleration and greater responsiveness - while optimizing the lifespan of your lift trucks battery and keeping maintenance requirements low.
  • IPX4 Waterproofing - Whether in a warehouse or in the rain, you can count on these trucks to keep running reliably, thanks to IPX4 waterproofing.
  • Go Longer with Regeneration - Innovative technology in the truck translates movements such as coasting, plugging, downhill travel, braking, speed suppression and controlled rollbacks into kinetic energy that charges the truck’s battery as it’s being used - extending operating time.
Reliability
Model Capacity Height Voltage Length Width Maximum Available Fork Height Weight
FB15CB 1,500 3000 48 V 2080 1100 2110 2,250
FB18CB 1,750 3000 48 V 2120 1115 2110 2,495
FB20CB 2,000 3000 48 V 2305 1155 2110 2,960
FB25CB 2,500 3000 48 V 2345 1155 2110 3,335
FB30CB 3,000 3000 48 V 2505 1255 2260 3,915
FB35CB 3,500 3000 48 V 2590 1255 2330 4,445
Sales Brochure- English

FB15CB-FB35CB Electric Pneumatic Tire Forklift Trucks
